SIGNALS AND SPECIAL FEATURES
Status Pro – T430 User Guide
4.5 Levelling-LED für X-/Z-Achse
4.6 LED’s around the Laser Aperture
Red (Y+)-LED
Red (Y-)-LED
Permanaently lit Axis is in levelling mode•
5Hz-Flash
Power-On- / Power-Off-Sequence•
Levelling not possible, outside of measurement range•
1Hz-Flash Temperature drift too large (usually during warm-up) – WAIT•
Permanently lit
Laser is being moved in the Y+ direction•
Calibration of Y- successful•
5Hz-Flash
Calibration could not be conducted•
Limiter for the Y-axis has been triggered (the end of position or•
the travel range has been reached or cannot be exited)
Short pulses Single steps in direction of Y+•
Permanently lit
Laser is being moved in the Y+ direction•
Calibration of Y- successful•
5Hz-Flash
Calibration could not be conducted•
Limiter for the Y-axis has been triggered (the end of position or•
the travel range has been reached or cannot be exited)
Short Pulses Single steps in direction of Y-•
Y+
Y-
