Steinberg CMC Series - Page 42

Appendix
CMC Series Operation Manual 42
CMC-QC
Buttons and Encoders
*0:Increase
1: Center Minimum
2: Increase
3: Decrease
4: Center Maximum
Function
MIDI Message
CMC (Device Port 1)
 PC
MIDI Message
CMC (Device Port 2)
 PC
MIDI Message
PC  CMC
Knob 1 Control Change B0 10 rr B0 30 xy
Knob 2 Control Change B0 11 rr B0 31 xy
Knob 3 Control Change B0 12 rr B0 32 xy
Knob 4 Control Change B0 13 rr B0 33 xy
Knob 5 Control Change B0 14 rr B0 34 xy
Knob 6 Control Change B0 15 rr B0 35 xy
Knob 7 Control Change B0 16 rr B0 36 xy
Knob 8 Control Change B0 17 rr B0 37 xy
QC mode – 90 2A kk 90 2A kk
f/Q LEARN – 90 32 kk 90 32 kk
EQ mode – 90 2C kk 90 2C kk
MIDI mode – 90 74 kk 90 74 kk
Function 1 – 90 36 kk –
Function 2 – 90 37 kk –
Function 3 – 90 38 kk –
Function 4 – 90 39 kk –
Shift – 90 46 kk –
Channel Select Left – 90 30 kk –
Channel Select Right – 90 31 kk –
Read – 90 51 kk 90 51 kk
Write – 90 4E kk 90 4E kk
Detail of Parameters
kk: 00 = OFF, 7F = ON
rr: 0x = CW, 4x = CCW
x: Lighting Type (0 – 4)*
y: Lighting Pattern (1 – B)
