Specifications 19
Chapter 4 - Specifications
Model 3315 Crane
SPECIFICATION SHEET
Crane Rating: 11,500 ft-lbs (1.59 ton-meters)
Standar
d Boom Length: 7’ (2.13 m) from CL of Crane
Boom Extension: 1st stage: Hydraulic 48" (121.9 cm)
2nd stage: Manual 48" (121.9 cm)
Maximum Horizontal Reach: 15’ (4.57 m) from CL of Crane
Maximum Vertical Lift: 16’ 9” (5.11 m)
(from crane base)
Boom Elevation: -5 to +80 degrees
Stowed Height: 32.5” (82.6 cm)
(crane only)
Mounting Space Required: 18” x 15” (45.7 x 38.1 cm)
Approximate Shipping Weight: 800 lbs (360 kg)
Controls: 20’ (6.1 m) cord with hand held control.
Winch Specifications
Rope Diameter: 1/4" (.64 cm)
Line pull speed: 30 ft/min (9.1 m/min)
Max. single part line: 1600 lbs (725 kg)
Max. double part line: 3200 lbs (1450 kg)
Rotation: 370 degree power
(worm gear)
Lifting Capacities: 1625 lbs @ 7’ (737 kg @ 2.1 m)
750 lbs @ 15’ (340 kg @ 4.6 m)
Power Supply Required: 12 volt power unit
(2.0 gpm @ 2300 psi)
(7.57 lpm @ 159 bars)
*Subject to change without notification
