stellar labs 3315 - Main Cylinder Assembly - PN 25676

42 3315 Owner’s Manual
Cylinder
Serial Tag
Location
5
CYLINDER BUSHINGS FOR REFERENCE ONLY
6
1
6
6
6
2
4
2
3
2
2
.Y
TQN
OI
TPI
RC
S
EDTRA
P
ME
TI
119017 CYLINDER 3.00X19.88 1
20279FTG ADAPT 6-F5OLO-S 4
313080 MANIFOLD SINGLE T11A 3500 PSI 1
419363 TUBE ASM 0.38X5.69 3315 1
515173 TUBE ASM 0.38X7.81 MAIN CYL 5520 1
6 0067 BUSHING BPC-2426-24 1.50X1.50 4
PN 25676
Main Cylinder Assembly - PN 25676
Note: Main Cylinder uses
Stellar Seal Kit P/N 11378
