stellar labs 3315 - Mast Assembly (Proportional Version)

37Assembly Drawings 37
4
4
4
4
2
8
1
5
7
3
6
RECEIVER SHOWN
AS REFERENCE
10
11
6
9
PN 50596
.Y
TQN
OI
T
P
I
RC
S
EDTRA
P
METI
1 50597 MAST 3315 HYD PROP H2 1
2C5902 WASHER 0.63 SAE FLAT YELLOW GR8 10
3C1026 CAP SCR 0.63-11X2.50 HHGR8 ZY 10
421810 BUSHING GSI-2426-12 1.50X0.75 4
5C0930 CAP SCR 0.31-18X3.00 HHGR5 2
5
TA
LF 52
.0
R
EH
SAW04306
70437 CAP SCR 0.25-20X1.25 HHGR5 2
850592 VB 4 SECT W/PROP STER4GPM DEUTSCH 1
90343 WASHER 0.31 USS FLAT ZINC 2
10 50599 MAST 3315 HYD PROP H2 1
11 0479 CAP SCR 0.25-20X0.75 HHGR5 3
Mast Assembly (Proportional Version) - PN 50596
