Specifications 
Chapter 4 - Specifications
Model 28000 Crane
SPECIFICATION SHEET
Crane Rating: 280,000 ft-lbs (38.71 ton meters)
Standard Boom Length: 13’ 2” (4.01 m) from CL of Crane
Boom Extension: Hydraulic 37" (94.0 cm)
Maximum Horizontal Reach: 16’ 3” (4.95 m) from CL of Crane
Maximum Vertical Lift: 25’ (7.62 m)
(From Truck Frame)
Cylinder Specifications
Inner Lift Cylinder: 9” (22.9 cm) bore with integral pilot
operated counterbalance valves.
Outer Lift Cylinder: 7” (17.8 cm) bore with integral pilot
operated counterbalance valves.
Extension Cylinder: 6” (15.2 cm) bore with integral pilot
operated counterbalance valves.
Rotation: 315 degree power
(planetary gear with pinion)
Lifting Capacities: 28,000 lbs @ 10’ (12,700 kg @ 3.05 m)
(From CL of Truck) 17,200 lbs @ 16’ 3” (7,800 kg @ 4.95 m)
Power Supply Required: PTO & Pump
(16 gpm @ 4,200 psi)
(60 lpm @ 290 bars)
Controls: Fully Proportional Paddle Controls for all
functions.
Stowed Height: 114” (289.6 cm)
(Above Truck Frame)
Mounting Space Required: 48” (121.9 cm)
Approximate Shipping Weight: 13,000 lbs (5,895 kg)
