stellar labs Model 28000 - Outrigger Cylinder Assembly - PN 48383

Assembly Drawings 
Note: BUSHINGS ARE SHOWN FOR REFERENCE.
1
5
4
2
4
6
5
3
3
6
.YTQNOITPIRCSEDTRAPMETI
148384 CYLINDER 7.00X19.25 1
215822 MANIFOLD DOUBLE T11A 5000 PSI 1
3D1290 FTG ADAPT 8-6 F5OLO-S 2
40279 FTG ADAPT 6-F5OLO-S 2
519032 TUBE ASM 0.38 X 6.91 2
60635 BUSHING 40DXR32 GARLOCK 4
PN 48383
Outrigger Cylinder Assembly - PN 48383
