HYDRAULIC SYSTEM COMPONENTS
PART# DESCRIPTION
39780 Oil pressure gauge
8240 Oil cooler
22934 Hydraulic rotation motor ( Crane rotation )
22935 Valve block hydraulic motor (Crane rotation)
28485 Pressure transducer (overload)
41338 High pressure filter asm
47860 High pressure filter element (Used in p/n 41338)
18552 Fill cap assy with neck (Hydraulic reservoir)
15463 Thermo sight gauge (Hydraulic reservoir)
11149 Gasket - (Optional Artic heater cover)
C6327 Filter Strainer ( Hydraulic reservoir )
42184 Hydraulic return filter asm (Hydraulic reservoir)
47820 Hydraulic filter element (Used in p/n 42184)
47866 Control Handle - Valve bank (PVG32)
C1090 Counter balance valve ( Cylinders)
C6184 Counter balance valve (Extension & Outrigger cylinders)
15995 Manifold asm dual T2 - 5000 psi (Cylinder)
42802 Valve bank - 7 section
40827 Valve bank - 5 section
55401 Relief valve - (5 section valve bank)
50234 Dump valve - (7 section valve bank)
50235 Dump valve coil - (7 section valve bank)
47871 Valve - LMI system
13555 Hydraulic quick coupler
13554 Hydraulic quick coupler
13557 Hydraulic quick coupler
13556 Hydraulic quick coupler
C2028 O ring ( # 6 face seal ) ( hydraulic fittings )
C2029 O ring ( # 8 face seal ) ( hydraulic fittings )
32223 O ring (#10 face seal ) ( hydraulic fittings )
D1244 O ring (#12 face seal ) ( hydraulic fittings )
D1245 O ring (# 4 SAE port side ) ( hydraulic fittings )
D1246 O ring (# 6 SAE port side ) ( hydraulic fittings )
D1247 O ring (# 8 SAE port side ) ( hydraulic fittings )
D1248 O ring (#10 SAE port side ) ( hydraulic fittings )
D1249 O ring (#12 SAE port side ) ( hydraulic fittings )
D1250 O ring (#16 SAE port side ) ( hydraulic fittings )
16158 Port tube asm - ( 15604 secondary cylinder )
35647 Seal kit - Outrigger cylinder ( 9994 )
C6310 Seal kit - Outrigger cylinder ( 9993 )
35651 Seal kit - Main lift cylinder ( 15598 )
35650 Seal kit - Secondary cylinder ( 15604 )
35649 Seal kit - Extension cylinder ( 15608 )
ASSEMBLY COMPONENTS
PART# DESCRIPTION
0635 Bushing 2.50" x 2.00"
0865 Bushing 3.00" x 2.00"
2227 Bushing 3.00" x 3.00"
4381 Bushing 2.00" x 2.00"
5739 Bushing 2.50" x 3.00"
8819 Bushing 2.00" x 1.00"
13343 Bushing 2.50" x 1.00"
13817 Bushing 2.50" x 1.50"
17320 Bushing 2.50" x 2.50"
25574 Bushing 2.50" x 1.75"
8377 Pin Cap 0.56 x 3.50" x .25 SS
8597 Pin Cap 0.69 x 4.00" x .25 SS
9142 Pin Cap 0.56 x 2.50" x .25 SS
10172 Cap Screw 0.50-13 x 1.00 Gr 8
D0790 Washer 0.50 Flat Gr 8
2257 Snap ring 2.00" Internal
C5644 Grease Zerk 1/8 NPT 45 degree (Grease line kit option)
C1592 Grease Zerk 1/8 NPT (Cylinders / pivot points)
40455 Wear Pad 2.00" x 8.00" x 1.50"
15779 Wear Pad 3.00" x 5.00" x 1.75"
15778 Wear Pad 3.00" x 5.00" x 2.44"
15601 Wear Pad 1.00" x 4.00" x 12.00"
17133 Hose clamp
39959 Gear bearing rotation kit
16054 Swivel link ( 15-ton hook )
16052 Hook 15-ton Swivel
ELECTRICAL COMPONENTS
PART# DESCRIPTION
41922 Hetronic Nova radio system
47862 12v charger for Hetronic Nova radio system
47863 Battery for Hetronic Nova radio system
47867 Belt - Transmitter harness (waist)
8241 Fan 16.00 push 12 V ( Hydraulic reservoir )
6394 Toggle switch ( Outrigger operation )
8623 Toggle switch ( Outrigger operation )
C4815 Toggle switch ( Outrigger operation )
54393 Temperature switch ( Hydraulic reservoir )
22921 E-stop switch ( Crane panic bar )
61562
41367 LMI system (Load Moment Indicator)
31782 Wire harness - LMI & Lights
41368 Wire harness - LMI Cinch Retro
D0045 Overload alarm
COMPRESSOR COMPONENTS (SHD245 OPTIONAL)
PART# DESCRIPTION
3853 Pilot valve 145/175 psi (SHD245 cprsr)
C4913 Solenoid valve (SHD245 cprsr)
C4914 Pressure Relief valve (SHD245 cprsr)
C0864 Hobbs air pressure switch (SHD245 cprsr)
13731 Low pressure intake valve asm (SHD245 cprsr)
13733 High pressure intake valve asm (SHD245 cprsr)
SERVICE KITS / FILTERS / LUBRICATION
PART# DESCRIPTION
4562 Air filter (SHD245 cprsr)
32893 Service Kit - 200 hour (SHD245 cprsr)
4460 Molube grease-external gear teeth for swing gears
MISCELLANEOUS COMPONENTS
PART# DESCRIPTION
51263 Flood lights ( Crane & Body )
5033 Stobe light ( Crane & Body )
14022 Compartment light
