stellar labs Model 28000 - Main Boom Cylinder Assembly - PN 20694

Assembly Drawings 
3
2
4
5
5
4
6
2
3
1
PRESSURE SWITCH
IN THIS PORT
ITEM NO.PART NO.DESCRIPTION QTY
115598 CYLINDER 9.00x4.00x21.81 1
2 16153 FTG ADAPT 10-C5OLO-S2
32227BUSHING 48DXR48 GARLOCK 4
4 16157 TUBE ASM 0.63X7.88 YZ 2
5 16152 FTG ADAPT 10-F5OLO-S2
6 15995 MANIFOLD ASM DUAL T2A 5000PSI1
PN 20694
Main Boom Cylinder Assembly - PN 20694
