Technical data
Call point output
Voltage: 24 V (nominal)
Power: max. 60 mA, 100% ED
Terminal: max. 1.5 mm², spring terminal
Cable monitoring function: terminal resistor 10k
max. pieces: 10
Emergency power: yes
Automatic alarm unit output
Voltage: 24 V norminal
Power: max. 150 mA, 100 % ED
Terminal : max. 1.5 mm², spring terminal
Cable monitoring function: terminal resistor 10k or active end resistor
max. pieces: 10
Emergency power: yes
Wind rain detector output
Voltage: 24 V norminal, 20 V to 30 V DC
Power: max. 100 mA, 100 % ED
Terminal: max.1.5 mm², spring terminal
Cable monitoring function: no
max. pieces: 1, Typ WRM/RM/WRM2/RM2
Emergency power: no
Fuse: no
Floating potential contacts: yes, 3 x change over contact
(- SHE activation, - accumulative, - malfunction)
Contact load: max. 30 V / 2 A per contact
Signal SHE activation and
malfunction: optical, continuous signal in case of SHE activation,
alternating signal for malfunction
Mechanical properties
Dimensions: see page 78
Weight: type 4A: with battery approx. 6 kg, without battery approx. 4 kg
Typ 4A/M: with battery approx 6 kg, without battery approx 4 kg
type 8A: with battery approx. 11 kg, without battery approx. 4 kg
Typ 8A/M: with battery approx 14,9 kg, without battery approx 12,9 kg
Circuit connections and operation
Connections: see technical documentation
Terminal connections: see technical documentation
Suitable for SHE: yes
Suitable for ventilation: yes
Ventilation function in the event of
mains failure: no, ventilation blocked
Safety functions in the event of
mains failure: yes, automatic closure of the windows, ventilation blocked, while SHE
continues to be active: further functions via DIP-Switches
Maintenance
Battery replacement: every 4 years and in the event of battery malfunction
Maintenance counter: yes, adjustable via PC Service Port Software
Maintenance counter active: when power is supplied to the system, battery-backed
Functions after countdown of
maintenance counter: LED display
OK
OKashes,deactivation/activationofthe
via service port software
Compact control panel 4A, 4A/M und 8A, 8A/M
