Specication
17.10 Data table
Output details apply to new appliances with clean heat exchangers.
The power consumption of the integral auxiliary drives is stated as a maximum and may vary, subjectto operating point.
The power consumption of the integral auxiliary drives is already included in the output details of the heat pump, as specifi ed by the
EN 14511.
WPL 13 basic WPL 20 basic WPL 13 S basic WPL 18 S basic
230385 230386 230387 230388
Heating output to EN 14511
Heating output at A-7/W35 (EN 14511) kW 6.39 10.43 6.69 8.89
Heating output at A2/W35 (EN 14511) kW 8.5 12.9 9.07 11.6
Heating output at A7/W35 (EN 14511) kW 10.69 15.17 10.86 13.62
Heating output at A10/W35 (EN 14511) kW 11.76 18 11.82 16.10
Power consumption
Power consumption, fan heating max. kW 0.13 0.13 0.13 0.13
Power consumption, emergency/booster heater kW 8.8 8.8 6.2 6.2
Power consumption to EN 14511
Power consumption at A-7/W35 (EN 14511) kW 2.19 3.69 2.34 3.93
Power consumption at A2/W35 (EN 14511) kW 2.35 3.84 2.48 3.42
Power consumption at A7/W35 (EN 14511) kW 2.43 3.96 2.57 3.51
Power consumption at A10/W35 (EN 14511) kW 2.43 4.1 2.59 3.56
COP to EN 14511
COP at A-7/W35 (EN 14511) 2.92 2.82 2.86 2.26
COP at A2/W35 (EN 14511) 3.62 3.36 3.66 3.39
COP at A7/W35 (EN 14511) 4.4 3.83 4.23 3.88
COP at A10/W35 (EN 14511) 4.84 4.39 4.56 4.52
Sound data
Sound power level outdoor installation (EN 12102) dB(A) 68 70 70 73
Sound power level indoor installation, air intake/discharge (EN 12102) dB(A) 62 64 62 62
Sound power level indoor installation (EN 12102) dB(A) 56 58 56 57
Application limits
Min. application limit on the heating side °C 15 15 15 15
Max. application limit on the heating side °C 60 60 60 60
Min. application limit, heat source °C -18 -18 -18 -18
Max. application limit, heat source °C 40 40 40 40
Water hardness °dH ≤3 ≤3 ≤3 ≤3
pH value (with aluminium compounds) 8.0-8.5 8.0-8.5 8.0-8.5 8.0-8.5
pH value (without aluminium compounds) 8.0-10.0 8.0-10.0 8.0-10.0 8.0-10.0
Chloride mg/l <30 <30 <30 <30
Conductivity (softening) μS/cm <1000 <1000 <1000 <1000
Conductivity (desalination) μS/cm 20-100 20-100 20-100 20-100
Oxygen 8-12 weeks after filling (softening) mg/l <0.02 <0.02 <0.02 <0.02
Oxygen 8-12 weeks after filling (desalination) mg/l <0.1 <0.1 <0.1 <0.1
Energy data
Energy efficiency class, average climate, W55/W35 A+/A+ A+/A+ A+/A+ A+/A+
Electrical data
Compressor fuse/MCB A 3 x C 16 3 x C 16 1 x C 25 1 x C 25
MCB/fuse protection, controller A 1 x B 16 1 x B 16 1 x B 16 1 x B 16
MCB/fuse protection, emergency/booster heater A 3 x B 16 3 x B 16 1 x B 16 1 x B 16
Frequency Hz 50 50 50 50
Phases, compressor 3/N/PE 3/N/PE 1/N/PE 1/N/PE
Phases, controller 1/N/PE 1/N/PE 1/N/PE 1/N/PE
Phases, emergency/booster heater 3/N/PE 3/N/PE 1/N/PE 1/N/PE
Starting current (with/without starting current limiter) A 21/- 25/- <45/89 <45/89
Rated voltage, compressor V 400 400 230 230
Rated voltage, controller V 230 230 230 230
Rated voltage, emergency/booster heater V 400 400 230 230
Versions
Condenser material 1.4401/Cu 1.4401/Cu 1.4401/Cu 1.4401/Cu
Refrigerant R407 C R407 C R407 C R407 C
Refrigerant charge kg 2.65 2.7 2.56 2.65
Defrost type Circuit reversal Circuit reversal Circuit reversal Circuit reversal
IP rating IP14B IP14B IP14B IP14B
