18 ACCESSORIES
EN
The table contains a list of all possible combina-
tions between bar and chain, indicating those
which may be used on each machine, marked with
the symbol “ ”.
In consideration that the
selection, application and usage of bar and
WARNING!
chain are actions made solely by the user, the
latter assumes responsibility for damages of
any kind due to such actions. When in doubt or
if lacking knowledge of the specificity of each
bar or chain, contact your retailer or spe-
cialised gardening centre.
10. ACCESSORIES
Bar and chain combinations
Pitch BAR CHAIN Model
Inches
Length
Inches / cm
Groove
width
Inches / mm
Code Code
36 43 46 52
3/8" 14" / 35 cm 0,050"/1,3mm 118800623/0 4113703
325" 15" / 38 cm 0,058"/1,5mm 118800624/0 4113724
325" 18" / 45 cm 0,058"/1,5mm 118800625/0 4113722
