Stihl 034 Series User Manual

6 034, 036, 036 QS
3.5 Tightening Torques
DG and P (Plastoform) screws are used in polymer and lightmetal components. These screws form a
permanent thread when they are installed for the first time. They can be removed and installed as often as
necessary without impairing the strength of the screwed assembly, providing the specified tightening torque is
observed.
For this reason it is essential to use a torque wrench.
Fastener Thread size For component Torque
Nm
Remarks
Pan head screw M4x8 Chain tensioner cover plate 3.0
M7x12.5 Starter post to fan housing 12.0 1)
Screw M8x22 Brake band/crankcase
(036 QS II) 10.0 2)
Self-tapping screw B3.9x13 Brake cable retainer/tank housing (036 QS II) 1.5
Collar screw M8x21.5 Guide bar 23.0 2)
Spline screw IS-M4x12 Cover, chain brake/crankcase 3.0
M10x1 Decompression valve (036, 036 QS) 14.0
Spline screw M3.5x12 Generator (W version) 2.0 3)
Spline screw IS-P6x21.5 Front handle/tank housing, top right
(W version) 7.0 3)
Spline screw IS-P6x19 Front handle/tank housing, bottom
(W version) 7.0 3)
Spline screw IS-P6x32,5 Front handle/tank housing, top right, polymer 5.0 3)
Spline screw IS-P6x21,5 Front handle/tank housing, bottom, polymer 5.0 3)
Spline screw IS-P4x19 Handle molding 1.6
Screw assembly M5x30 Hand guard, left 7.0 2)
Spline screw IS-P6x19 Chain catcher 2.8
Spline screw IS-M5x12 Spiked bumber 7.5
Spline screw IS-M5x20 Crankcase 9.0
Spline screw IS-M5x20 Fan housing/crankcase 7.0
M12x1 L Carrier 50.0
Screw HL6x18.5 Annular buffer to rear left/right of tank housing 5.0
Spline screw IS-P6x19 Annular buffer to front right of tank housing 5.0
Spline screw IS-M5x6 Muffler, upper/lower casing 6.5 2)
Spline screw IS-M5x25 Muffler/crankcase 10.0 2)
Spline screw IS-M5x16 Muffler/cylinder (036, 036 QS) 10.0 2)
Spline screw IS-M5x25 Muffler/crankcase (034) 10.0 4)
Spline screw IS-M5x20 Muffler/cylinder (034) 10.0 4)
Spline screw IS-M5x22 Muffler/cylinder (034/Z version) 10.0 4)
Slotted nut M5 Shroud 3.3
Slotted nut M5 Air filter 2.0
M8x1 Flywheel 33.0 6)
Setscrew M5x8.5 Setscrew, l/h side of cylinder 1.4 5)
Setscrew M5x8.5 Setscrew, r/h side of cylinder 1.4
