No. Part Name Part No. Application Rem.
32 Installing tool 5910 890 2202 Installing crankshaft
33 Installing tool 4126 893 4900 Removing rubber element
from AV sleeve
34 Circlip pliers 0816 610 1495 External circlip on
clutch drum
35 Pliers C19 0811 641 8380 Internal circuit in
clutch housing
36 T-handle screwdriver QI-T27x150 5910 890 2400 For all IS screws 7)
37 Screwdriver T20x100 5910 890 2301 Separating handle moldings
38 Assembly drift 1108 893 4700 Removing and installing
clutch drum 1) 2)
39 Vice jaws 5910 893 2700 Holding drive tube and bike
handle
40 Press arbor 1120 893 7200 Removing ball bearing in
clutch housing
41 Press arbor 1118 893 7200 Installing ball bearing in
clutch housing,
removing and installing
ball bearing in bearing
housing (support frame) 2)
42 Assembly stand 5910 890 3100 Holding FS and FR units
43 - Clamp 5910 890 8800 Holds drive tube of FS units
for repairs
(in conjunction with assembly stand)
44 - Clamping plate 5910 890 2101 Holds powerhead of FS and
FR units for repairs
(in conjunction with assembly stand)
Remarks:
1) FS 120...350
2) FR 350/450
3) FS 400/450
4) Equivalent to puller 0000 890 4400, but with longer spindle 5910 890 8400.
5) Always use torque wrench to tighten DG/P screws.
6) Wrench has optical/acoustic signal.
7) On DG/P screws, use for releasing only.
60 FS 120, 200, 300, 350, 400, 450, FR 350, 450
