Stihl FS 50 Instruction Manual

FS 40, FS 40 C, FS 50, FS 50 C
English
37
FS 40, FS 40 C
FS 50, FS 50 C
Ignition System
Electronic magneto ignition
Fuel System
All position diaphragm carburetor with
integral fuel pump
Weight
Dry, without cutting attachment and
deflector
Overall length
without cutting attachment
Users of this unit should carry out only
the maintenance operations described
in this manual. STIHL recommends that
other repair work be performed only by
authorized STIHL servicing dealers.
Warranty claims following repairs can be
accepted only if the repair has been
performed by an authorized STIHL
servicing dealer using genuine STIHL
replacement parts.
Genuine STIHL parts can be identified
by the STIHL part number, the
{ logo and, in some cases, by
the STIHL parts symbol K. The
symbol may appear alone on small
parts.
Displacement: 1.66 cu. in
(27.2 cc)
Bore: 1.34 in (34 mm)
Stroke: 1.18 in (30 mm)
Engine power to
ISO 8893:
0.9 HP (0.7 kW)
at 8,500 rpm
Idle speed: 2,800 rpm
Cut-off speed (rated): 10,000 rpm
Max. output shaft
speed (cutting
attachment): 10,600 rpm
Displacement: 1.66 cu. in
(27.2 cc)
Bore: 1.34 in (34 mm)
Stroke: 1.18 in (30 mm)
Engine power to
ISO 8893
1.1 HP (0.8 kW)
at 8,500 rpm
Idle speed: 2,800 rpm
Cut-off speed (rated): 10,000 rpm
Max. output shaft
speed (cutting
attachment): 10,600 rpm
Spark plug (resistor
type): NGK CMR 6 H
Electrode gap: 0.02 in (0.5 mm)
Fuel tank capacity: 11.5 fl.oz (0.34 l)
Standard version
FS 40: 9.7 lbs
(4.4 kg)
FS 50: 9.7 lbs
(4.4 kg)
FS 50: with long
shaft
9.9 lbs
(4.5 kg)
Versions with Easy2Start
FS 40 C: 9.9 lbs
(4.5 kg)
FS 50 C: 9.9 lbs
(4.5 kg)
FS 50 C: with long
shaft
10.1 lbs
(4.6 kg)
FS 40,
FS 40 C: 57 in (1450 mm)
FS 50,
FS 50 C: 57 in (1450 mm)
FS 50,
FS 50 C:
with long
shaft 65 in (1650 mm)
Maintenance and Repairs

Stihl FS 50 Specifications

General

Engine Displacement	27.2 cc
Power Output	0.8 kW
Engine Type	2-stroke
Shaft Type	Straight
Starter System	Recoil
Overall Length	147 cm
Vibration Level	4.5 m/s²
