0458-004-0121-A
26
English
14 Cleaning
14.2 Cleaning nozzle and spray lance
► Rinse the nozzle and spray lance under running water and
dry with a cloth.
► If the nozzle is clogged: Clean the nozzle with the cleaning
pin.
14.3 Cleaning the water intake screen
► Unscrew the connector (1) of the water connection.
► Remove water intake screen (2) from the connector.
► Rinse out the water intake screen (2) under running water.
► Insert water intake screen (2) into the connector.
► Attach the connector (1) and tighten it by hand.
14.4 Cleaning the water filter
The water filter must be disassembled to clean it.
► Remove the seal (1) from the filter housing (3).
► Take the filter (2) out of the filter housing (3).
► Rinse out the seal (1) and the filter (2) under running
water.
► Grease the gasket (1) with a fitting grease.
► Reassemble the water filter.
0000098884_001
1
2
3
0000099083_001
