3 Overview
2 Holders
The holder is used for storing the spray gun.
3 Holders
The holder is used for storing the spray attachment.
4 Carrying handle
The carrying handle is used to carry the high-pressure
washer.
5 Rocker switch
The rocker switch is used to switch the high-pressure
washer on and off.
6 Connector
The connector is used to connect the water hose.
7 Guide opening
The guide opening guides the high-pressure hose from
the front onto the hose reel.
8 Crank handle
The crank handle is used to turn the hose reel.
9 Holders
The holder is used to remove and to store the connecting
cable.
10 Mains plug
The mains plug connects the connecting cable to a
socket.
11 Connecting cable
The connecting cable connects the high-pressure
washer to the mains plug.
12 Connector
The connector is used to connect the water hose.
13 Compartments
The compartments are used to store the supplied
nozzles.
14 Detergent bottle
The detergent bottle is used when cleaning with
detergents.
15 High-pressure hose
The high-pressure hose transports the water from the
high-pressure pump to the spray gun.
16 Hose reel
The hose reel is used to roll up the high-pressure hose.
# Rating plate with machine number
3.2 Spray attachment
1 Spray lance
The spray lance connects the spray gun to the nozzle.
2 Spray gun
The spray gun is used to hold and control the spray
attachment.
3 Control Panel
The control panel is used to display and set the working
pressure.
4 Trigger
The trigger opens and closes the valve in the spray gun.
The trigger starts and stops the water jet.
5 Retaining latch
The retaining latch releases the trigger.
4
6
1
2
3
5
13
11
12
10
9
7
8
