Stihl RE 80 - High Pressure Washer STIHL RE 80.0 X; Lubricating the Seals; Specifications

0458-001-9621-A
68
English 19 Specifications
18.2 Lubricating the seals
► Grease the seals (1) with grease for fittings.
19.1 High pressure washer STIHL RE 80.0 X
Version 100 V / 50-60 Hz
– Fuse (characteristic "C" or "K"): 15 A
– Power consumption: 1.4 kW (EU) 2019/1781 §2(2) (j)
– Maximum permitted network impedance: 0.15 Ohm
– Protection class: II
– Degree of of electrical protection: IPX5
– Working pressure (p): 6.7 MPa (67 bar)
– Max. permissible pressure (p max.): 10 MPa (100 bar)
– Max. water supply pressure (p in max.): 1 MPa (10 bar)
– Max. water throughput (Q max.): 7.5 l/min (450 l/h)
– Minimum water throughput (Q min.): 5.4 l/min (320 l/h)
– Max. suction lift: 0.5 m
– Max. water temperature in pressure mode (t in max):
40 °C
– Max. water temperature in suction mode: 20 °C
– sample inspection
– Length: 250 mm
– Width: 270 mm
– Height: 430 mm
– Length of high-pressure hose: 5 m
– Weight (m) with accessory attached: 7 kg
Version 120 V - 127 V / 60 Hz
– Fuse (characteristic "C" or "K"): 15 A
– Power consumption: 1.5 kW (EU) 2019/1781 §2(2) (j)
– Maximum permitted network impedance: 0.15 Ohm
– Protection class: II
– Degree of of electrical protection: IPX5
– Working pressure (p): 7.2 MPa (72 bar)
– Max. permissible pressure (p max.): 10 MPa (100 bar)
– Max. water supply pressure (p in max.): 1 MPa (10 bar)
– Max. water throughput (Q max.): 7.2 l/min (430 l/h)
– Minimum water throughput (Q min.): 5.5 l/min (330 l/h)
– Max. suction lift: 0.5 m
– Max. water temperature in pressure mode (t in max):
40 °C
– Max. water temperature in suction mode: 20 °C
– sample inspection
– Length: 250 mm
– Width: 270 mm
– Height: 430 mm
– Length of high-pressure hose: 5 m
– Weight (m) with accessory attached: 7 kg
Version 127 V / 60 Hz
– Fuse (characteristic "C" or "K"): 15 A
– Power consumption: 1.5 kW (EU) 2019/1781 §2(2) (j)
– Maximum permitted network impedance: 0.15 Ohm
– Protection class: II
19 Specifications
1
1
1
0000098483_001
