0458-814-8221-A
26
English
11 During Operation
Attach the detergent spray set (4) to the spray lance (3).
Spray the detergent onto the surface to be cleaned.
When applying detergent, start at the bottom of the
surface and work upwards. Do not allow the detergent to
dry.
After applying detergent:
Switch off the pressure washer, @ 10.2.
Relieve system pressure.
Lock the spray gun trigger.
Remove the detergent spray set.
Re-attach the fan-jet nozzle or rotary-jet nozzle.
Spray the surface until it is clean and any remaining
detergent is washed away.
When rinsing off detergent, start at the top of the surface
and work down.
11.3 Cleaning
WARNING
To reduce the risk of personal injury, never work with the
pressure washer in the rain, @ 5.5. Always wear proper
clothing and protective apparel, including proper eye
protection, when operating your pressure washer, @ 5.4.
Keep bystanders away from the work area, @ 5.8.4. Work
carefully and maintain proper control of the pressure
washer, @ 5.8.2.
WARNING
To reduce the risk of fluid injection and/or severe injury,
keep hands, feet or any other part of your body away from
the water jet at all times and never direct the high-pressure
jet toward yourself or other persons, not even to clean
clothing or shoes, @ 5.8.4. Do not direct the high-pressure
jet toward animals.
Depending on the application, the following nozzles may be
used:
Fan-jet nozzle: The fan-jet nozzle is designed for cleaning
larger areas.
Rotary-jet nozzle: The rotary nozzle is designed for
removing stubborn dirt.
If you want to remove stubborn dirt, reduce the distance
between the nozzle and the surface.
If you want to remove dirt from painted, wooden or other
potentially sensitive surfaces, increase the distance
between the nozzle and the surface.
To adjust the fan jet nozzle:
WARNING
To reduce the risk of injury from high-pressure spray, always
switch off the pressure washer, relieve any remaining
pressure in the system and lock the spray gun trigger before
attempting to insert, adjust or remove the spray nozzle.
Switch off the pressure washer.
Relieve system pressure.
Lock the spray gun trigger.
0000-GXX-5097-A0
4
3
500 ml
400 ml
300 ml
200 ml
100 ml

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Stihl RE 90 and is the answer not in the manual?

Stihl RE 90 Specifications

General IconGeneral
Form factorUpright
Hose length6 m
Power sourceElectric
Castor wheelsYes
Product colorBlack, Grey, Orange
Detergent tank-
Pressure rangeHigh-pressure
Protection classII
International Protection (IP) codeIPX5
Maximum pressure100 bar
Maximum flow rate450 l/h
Minimum flow rate336 l/h
Working pressure (max)72 bar
Maximum water temperature40 °C
Fuse15 A
AC input voltage127 V
AC input frequency60 Hz
Power consumption (typical)1600 W
Weight and Dimensions IconWeight and Dimensions
Depth290 mm
Width330 mm
Height860 mm
Weight8800 g
