Stihl RE 90 User Manual

0458-814-8221-A
4
English 3 Main Parts
3.1 Pressure Washer
1 Pushbar
For pushing the pressure washer.
2 Holder for Spray Gun
For storing the spray gun.
3 Holder for Spray Attachment
For storing the entire spray attachment consisting of
spray gun and spray lance.
4 Carrying Handle
For lifting and transporting the pressure washer.
5 Connector for High-Pressure Hose
For connecting the high-pressure hose to the high-
pressure pump.
6 Power Switch
Switches the motor on and off.
7 Brackets for Power Supply Cord
For storing the power supply cord.
8 Power Supply Cord
Supplies the pressure washer with electricity when
connected to an electrical outlet (power supply).
9 Clip
For securing the power supply cord on the brackets.
10 Plug
Connects the power supply cord to an electrical outlet.
11 Connector for Water Inlet
For connecting the water hose to the high-pressure
pump.
12 Storage Compartment
For storing the high-pressure nozzles.
13 Holder for Detergent Spray Set
For storing the detergent spray set.
14 Bracket for High-Pressure Hose
For storing the high-pressure hose.
15 Cleaning Needle
Designed to help remove dirt and debris from the spray
nozzles.
3Main Parts
0000-GXX-6392-A0
13
12
10
7
8
9
15
14
11
1
2
3
4
5
6
#

Stihl RE 90 Specifications

General

Form factor	Upright
Hose length	6 m
Power source	Electric
Castor wheels	Yes
Product color	Black, Grey, Orange
Detergent tank	-
Pressure range	High-pressure
Protection class	II
International Protection (IP) code	IPX5
Maximum pressure	100 bar
Maximum flow rate	450 l/h
Minimum flow rate	336 l/h
Working pressure (max)	72 bar
Maximum water temperature	40 °C
Fuse	15 A
AC input voltage	127 V
AC input frequency	60 Hz
Power consumption (typical)	1600 W

Weight and Dimensions

Depth	290 mm
Width	330 mm
Height	860 mm
Weight	8800 g
