# Rating Plate
Contains electrical information and the product's serial
number.
3.2 Spray Attachment
1 Coupling for High-Pressure Nozzle
For connecting a spray nozzle to the spray lance.
2 Spray Lance
Directs the water from the spray gun to the high-pressure
nozzle.
3 Spray Gun
For controlling and directing the water jet.
4 Retaining Latch
Locks/unlocks the spray gun trigger.
5 Spray Gun Trigger
Opens and closes the valve in the spray gun.
6 Coupling for High-Pressure Hose
For connecting the high-pressure hose to the spray gun.
7 High-Pressure Hose
Transports the water from the high-pressure pump to the
spray gun.
8 Coupling
For connecting the high-pressure hose to the high-
pressure pump.
9 Coupling
For connecting the high-pressure hose to the spray gun.
10 Cleaning Needle
Designed to help remove dirt and debris from the spray
nozzles.
11 Detergent Spray Set
Used for adding detergents.
12 Detergent Bottle
For adding detergent while cleaning.
13 Detergent Nozzle
Designed to mix and spray detergent with water.
14 Rotary-jet Nozzle
Rotating nozzle for removing stubborn dirt.
15 Fan-jet Nozzle
Universal nozzle for cleaning larger surfaces.
4.1 Pressure Washer
The following safety symbols are found on the pressure
washer:
6
1 3 4
5
2
10
7
8
13
0000-GXX-5291-A0
9
14
15
12
11
4 Safety Symbols on the Product
To reduce the risk of injury, follow the specified
safety precautions.
Read and follow all safety precautions in the
instruction manual. Improper use can lead to
serious or fatal personal injury or property
damage.
