Stobag MOVENO Tandem DWIR-E - Programming; Programming Warnings and Time Limits; Limit Switch Programming; RDC Function Note

EN
5.6-Settingforceonclosure:“RDC”function
Caution! - The “RDC” level can only be personalised after programming the limit positions “0” and “1”, using the Semi-automatic procedure (paragraph 5.5).
01.UsetheUporDownbuttontomovetheawningtothepointofmid-travel.
02.PressandholdtheUppushbuttonuntiltheawningreacheslimitposition“0”(donotreleasethebutton).
03.Then,withtheAscentbuttonstillpressed,presstheDescent buttonthenumberoftimesastheleveltobeselected(presseachtimefor1second,withapause
of1secondbeforepressingagain).WiththeUpbuttonstillpressed,waituntiltheawningcompletesthesamenumberofmovements(inthedowndirection)as
thenewlevelset.Thelevelsavailableare:
level 1=maximumforce(factorysetting.)/level 2=mediumforce/level 3=minimumforce
04.ThenreleasetheUpbutton.
English–17
5.7-Deletingtheentirememory
Caution! - This procedure deletes all data in the Con trol unit memory, including positions “0” and “1”.
01.UsetheUporDownbuttontomovetheawningtothepointofmid-travel.
02. PressandholdtheUpandDownbuttonssimultaneouslyandwaitfortheawningtoperformashortmovement,afterwhichreleaseonlyoneofthetwobuttons
03. With3secondsaftertheawninghasperformedtheshortmovement,pressthepreviouslyreleasedbutton(inpoint02)threetimes.
04. Thereleasetheotherpushbutton.
Power supply voltage:seespecicationsonthemotordataplate
Power absorption on standby:0,5W
Encoder resolution:2,7°
Continuous operation time:4min
Operating temperature:-20°C
IP Protection rating:IP44
Note:
–Alltechnicalcharacteristicsrefertoanambienttemperatureof20°C(±5°C).
–STOBAGreservestherighttoapplymodicationstotheproductatanytimewhen
deemednecessary,whilemaintainingthesamefunctionalitiesandintendeduse.
TechnicalspecicationsDisposaloftheproduct
This product constitutes an integral part of the automation system, therefore it
must be disposed of along with it.
Asininstallation,alsoattheendofproductlifetime,thedisassemblyandscrapping
operationsmustbeperformedbyqualiedpersonnel.
Thisproductismadeupofdifferenttypesofmaterial,someofwhichcanberecy-
cledwhileothersmustbedisposedof.Seekinformationontherecyclinganddis-
posalsystemsenvisagedbythelocalregulationsinyourareaforthisproductcat-
egory.Caution!-somepartsoftheproductmaycontainpollutantorhazardous
substanceswhich,ifdisposedofintotheenvironment,maycause
seriousdamagetotheenvironmentorphysicalhealth.Asindicated
bythesymbolontheleft,disposalofthisproductindomesticwaste
isstrictlyprohibited.Separatethewasteintocategoriesfordisposal,
accordingtothemethodsenvisagedbycurrentlegislationinyour
area,orreturntheproducttotheretailerwhenpurchasinganewversion.Caution!
-Locallegislationmayenvisageseriousnesintheeventofabusivedisposalofthis
product.
x 1 = forza massima /
x 2 = forza media /
x 3 = forza minima /
04
0201
03
1/2 /3
THE
END
“0”
?
0201
x 3
03 04
THE
END
1
or
WeherebydeclarethatthisdeviceconformstothefundamentalrequirementsandrelevantprovisionsoftheCEdirectives.
Declarationofconformity:www.stobag.com
www.stobag.com
x 1=maximumforce/
x 2=mediumforce/
x 3=mediumforce/
