Stober SR6 User Manual

STOBER 5 | Technical data
05/2019 | ID 442790.01
29
Discharge times
Self-discharge of DC link 15min
Tab. 10: Discharge times of the DC link circuit
5.1.2 Electrical data
The electrical data of the available SC6 sizes as well as the properties of the brake chopper can be found in the following
sections.
Information
For the time span between two energizing processes, note that:
a) Direct, repeat activation of the supply voltage is possible for power-on/power-off operation.
b) A time span of > 15 must be observed between two energizing processes during continuous, cyclical power-on/
power-off operation with increased charging capacity.
Information
The STO safety function is available for safe shutdown as an alternative to continuous, cyclical power-on/power-off
operation.
An explanation of the symbols used for formulas can be found in Chapter Symbols in formulas [}203].
5.1.2.1 Control unit
Electrical data All types
U
1CU
24V
DC
, +20%/−15%
I
1maxCU
0.5A
Tab. 11: Control unit electrical data
