Stonex R60 – User Manual 33
Check the laser pointer spot
The laser pointer spot should be corresponded to the center of the aimed target.
1. Set up the tripod and instrument stable.
2. Power on the instrument and level it precisely.
3. Aim a cross/target located at 25 meters away from the instrument.
4. Verify that the center of the spot corresponds to the center of the target.
5. If the displacement is more than 2 mm respect the cross/target center, a calibration procedure is
required.
The laser pointer spot calibration needs to be carried out by an authorised service centre.
Check the viewfinder
1. Set up the tripod and instrument stable.
2. Power on the instrument and level it precisely.
3. Aim a cross/target located at 50 meters away from the instrument.
4. Observe the viewfinder whether collimating the cross mark.
5. If the viewfinder aims the cross/target, the adjustment is not necessary, if not a calibration
procedure is required.
The viewfinder calibration needs to be carried out by an authorised service centre.
