STONEX R60 - Technical Data

Stonex R60 – User Manual 34
6. Technical Data
ANGLE MEASUREMENT
Accuracy
1
1” / 2”
Reading system
Absolute encoder
Angle Units
DEG 360°/GON 400/MIL
6.400
Display resolution
0.1〞/ 0.00002g / 0.0005 mil
TELESCOPE
Magnification / Field of view
30x / 1°30’
Tube length
156 mm
Minimum focus distance
1.0 m (3.3 ft)
Reticle illumination
10 brightness levels adjustable
Effective aperture
Ø 45 mm
Laser pointer
Red light, coaxial
TILT SENSOR
Type
Dual axis
Compensation
range/accuracy
≥3.0′
DISTANCE MEASUREMENT RANGE
2
Prism mode
5.000 m
3
Reflective sheet (6 cm x 6 cm)
800 m
3
Reflectorless
6
1000 m
4
DISTANCE MEASUREMENT ACCURACY
5
Prism mode
2 mm + 2 ppm
Reflective sheet (6 cm x 6 cm)
3 mm + 2 ppm
Reflectorless
3 mm + 2 ppm
MEASUREMENT TIME
Prism
(Track/Fast/Standard)
0.4 / 0.6 / 1.0 sec
Reflectorless
1.5-5 sec
DISTANCE MEASUREMENT
Distance Units
m / US ft / INT ft
Display Resolution
0.0001 m / 0.001 m
0.00 1 ft / 0.01 ft
LASER PLUMMET
Laser type
635nm semiconductor laser
Accuracy
±1.0 mm @ 1.5 m
Spot
2.5 mm @ 1.5 m
LEVEL VIAL SENSITIVITY
Plate level
30“/ 2 mm
Circular level
8‘/ 2 mm
ENVIRONMENTAL CONDITIONS
Operating Temperature
-20°C to +50°C (-4°F to 122°F)
Storage Temperature
-40°C to +70°C (-40°F to 158°F)
Waterproof/Dustproof
IP55
PHYSICAL SPECIFICATION
Dimensions
358 x 211 x 220 mm
Weight including battery and
tribrach
6.5 Kg
POWER
Battery Voltage/Capacity/Type
7.2Vdc / 5200mAh /Li-ion
Batteries number
2
Operating time
Up to 8 hours (one internal
battery)
7
Battery charger
AC 100 - 240V, charging time 3h
OTHER SPECIFICATIONS
CPU
CORTEX-A55 Quad-Core
Display
5.5” color touch, 720 x 1280 px
OS
Android
Memory
4GB+32GB
Interface
USB type-A, USB type-C, RS232,
Bluetooth, Wi-Fi
Guide light
Yes
Sensors
Temperature / Pressure
ONBOARD FIELD APPLICATION PROGRAMS
Cube-a TS-GPS, R60 Manager
Specifications subject to change without notice.
1
Standard deviation based on ISO 17123-3
2
Good condition: cloudy, no haze, visibility about 40km, no heat shimmer, breeze. Under optimal conditions on Kodak Grey Card (90% reflective)
3
Class 1
4
Class 3R
5
Standard deviations based on ISO 17123-4
6 Under optimal conditions on good surface
7 Battery duration depends also on display brightness
