Wallrack User Manual
Triac Replacement
1. Disconnect the two flat cables.
2. Unplug the 2 red, 2 brown, 4 blue
and the green connectors.
(Please mark these cables before
unplugging them as you need to
replace them)
3. Unscrew the 4 choke connections.
User Manual v1.2 March 2006 24
