Ethernet Cables
Communications Line Planning 4-7
U117A Dual-Port
Fiber
10-Gbps Ethernet
PCI-Express
Adapter
Ordered in
pairs.
Typically
teamed for
fault
tolerance.
The maximum
distance between the
adapter and a hub or a
switch is 984 ft
(300m).
The customer must supply a
multi-mode fiber (MMF), 50/125 mm
dual-fiber cable rated with the OM3
performance code, with LC-type
connectors to the PCIe adapter,
and connectors on the other end
that are compatible with your site
network switch.
U584 Dual-Port
Fiber 10-Gigabit
Ethernet
PCI-Express
Adapter
Ordered in
pairs.
Typically
teamed for
fault
tolerance.
The maximum
distance between the
adapter and a hub or a
switch is 984 ft
(300m).
The customer must supply a
multi-mode fiber (MMF), 50/125 mm
dual-fiber cable rated with the OM3
performance code, with LC-type
connectors to the PCIe adapter,
and connectors on the other end
that are compatible with your site
network switch.
U118 Dual-Port
RJ-45 10-Gigabit
Ethernet
PCI-Express
Adapter (RJ-45
copper)
Ordered in
pairs.
Typically
teamed for
fault
tolerance.
The maximum
distance between the
adapter and a hub or a
switch is
328 ft (100m).
The customer must supply a
Category-6A Ethernet cable.
10GbE Embedded
Ethernet Port
4 N/A. You must supply
these cables.
The maximum
allowable distance
from these ports to a
switch or a hub is
328 ft (100m) for
Category-6A wire, and
180 ft (55m) for
Category-6 wire.
22 AWG Unshielded Twisted Pair
(UTP) EIA/TIA-Verified, Category-6
or Category-6A wire, with RJ-45
modular connectors terminated with
pair-wiring adhering to the
TIA/EIA-568-B.2-10 standard
Table 4-4. Customer-Supplied Ethernet Cables (Continued)
Component Quantity Cable Length Cable Type
