Product description
V 152 10 11 Rev.: END
3-4
3.5
Technical data
PP 1207
Gantry height 1958 mm 2158 mm
Dimensions (Width x depth
x height)
1844 x 1067 x 2868 mm
1844 x 1067 x 3068 mm
Height of filling hole 1145 mm
Doorway 400 mm 600 mm
Kerb weight approx. 2200 kg approx. 2300 kg
Operating voltage 400 V / 3 phases / 50 Hz / N / PE
Motor power 4 kW
Total connected load 4.5 kW
Protection class IP 54
Fuse protection 3 x 16 A (tripping characteristic C)
Supply line NYM 5 x 2.5 mm² with 16 A CEE connector
Installation location Inside / outside, roofed
Pressing weight 580 kN
Bale dimensions 580 kN
Noise level below 80 dB(A)
Plus 70
Gantry height in mm 2.149
Dimensions (Width x depth x height) in
mm
2117 x 1349 x 3069
Height of filling hole in mm 1155
Weight in kg approx. 2600
Stroke length in mm 690 890 1090
Operating voltage 400 V / 3 phases / 50 Hz / N / PE
Motor power in kW 4 9,2
Motor power in kW 4 9,2
Protection class IP 54
