Transportation and
installation
V 152 10 11 Rev.: END
4-3
4.3
Transportation with floor conveyor
Danger!
Life-threatening crush injuries during transportation of the gantry
press!
Improper lifting and transportation may cause the gantry press to
tip over and fall down!
Close the gantry press completely. This will avoid any centre of
gravity displacement and the associated risk of tipping over!
Never stand under suspended loads!
The following floor conveyors are permitted for transportation of the system
components:
– Transport system roller pallets with transport vehicle,
– forklifts and
– pallet trucks.
Information!
The supporting forks must be long enough so that the gantry press rests
fully on the forks.
● Ensure that the front side of the machine is not approached too closely.
● Select the minimum distance of the forks to prevent the machine from tipping
over.
The minimum load-bearing capacity of the forklift must withstand the weight of the
gantry press. When lifting the gantry press, ensure that the height difference between
two sides does not exceed 100 mm.
● Always avoid blows and impacts.
4.4
Assembly
4.4.1
Installation
Install the gantry press on a level and non-slip underground. The underground must
resist a surface load of at least 1000 kg/m². The feet must all be on the floor at the
same time.
Check the gantry press using the checklist.
