Strider MX 3 - Components; The Strider Scooter Overview; Dashboard Displays and Controls

14
Issued: 24.02.2005
STRIDER MX
Rear view
mirror
Operation indicator
(fault display)
Components
4.0 Components
4.2 The dashboard - displays and controls
Speed
contoller
Battery charge
display
Drive lever
(reverse)
Drive lever
(forwards)
Horn
button
Hazard
indicator switch
Headlight
switch
Indicator
switch
Shopping
basket
Tiller
Indicators
and rear
light
Drive unit
covers
Handle Handle
4.1 The Strider
Brake lever for
handbrake
Steering
wheel
Dashboard
with controls
Seat unit
with head-
and
armrests
Speed switch
