28
Issued: 24.02.2005
STRIDER MX
Always adjust the tiller so that you can
reach all displays and controls easily at any
time. The tiller can be variably adjusted.
Push or pull the locking lever (1).
Push the tiller forwards or backwards
into the required position (2).
Release the locking lever.
Ensure that the tiller is engaged correctly
by moving it backwards and forwards.
➨
➨
➨
➨
Accident hazard due to
non-engaged tiller!
• Ensure that the tiller is properly
engaged after adjustment by
pushing it slightly forwards and
then backwards.
adjusting the tiller
Adjusting the seat position
6.4 Adjusting the tiller angle
