Strider MX 3 - Replacing Rear Light Bulb

87
Issued: 24.02.2005
STRIDER MX
Bulb version used: 24 V / 5 Watt
(glass base lamp)
Loosen the fixing screw (1) and remove
the front or rear light lens.
➨
Insert the rear or front light lens and
secure with the fixing screws.
➨
18.5.2 Replacing bulbs in rear light
Repairs - lighting
Removing the lamp lens
2.) Align the bolt base with the bulb
holder and press the bulb in.
➨
Removing the bulb
Fitting a new bulb
1.) Pull the bulb out of the lamp holder.➨
