Strider MX 3 - Adjusting the Handbrake

82
Issued: 24.02.2005
STRIDER MX Repairs - mechanics
Loosen the adjustment element locknut
(4) on the front wheel.
Turn the adjusting screw (5) until
resistence can be felt at the brake lever
after about 1/3 of its operating distance
(a). (Apply brake lever lightly only).
➨
➨
Adjustments to the front
wheel
Hold the adjusting screw (5) immobile
and tighten the locknut (4) on the
adjusting element to accept the brake
cable (6).
➨
turn the locknut (2) until this contacts the
adjusting screw (3).
Turn the adjusting screw until it contacts
the handle.
➨
➨
18.3.5 Adjusting the handbrake
at the handlebars.
If this is not the case, then:
Braking adjustments - 3-wheel version:
Secure the Strider against rolling away.
Raise the side with the braked wheel and
support (see Chapter 19.0).
➨
➨
Before adjusting the brake, check that the
handle adjustment (1) is screwed fully in.
