24
Specification
1. Tuner & Demodulator
Input Frequency Range 950MHz ~ 2150 MHz
RF Input Signal Level -65 ~ -25dBm
RF Impedance 75W
RF Impedance 55MHz/8MHz(Under 5 Msps)
LNB Power 13/18DC, +/-5%, 0.5Amax,
1.8Apeak overloaded protect
LNB Tone Switch 22KHz +/- 2KHz, 0.65Vp-p+/-0.15V
DiSEqC Contro V1.0, V1.2, Tone burst A/B
Demodulation QPSK
Symbol Rate 1 ~ 45Msps/SCPC, MCPC
2.. MPEG
Transport Stream MPEG-2 ISO/IEC 13818
Transport Stream Specification
Input Rate Max.15Mbit/s
Video MPEG-2 MP@ML
Audio MPEG-1/2 Audio Layer1 or layer2
Video Resolution 720 x 576(PAL), 720 x 480(NTSC)
Audio Mode Stereo, Dual channel, Joint stereo,
Mono
Audio Sampling Frequency 32/44.1/48KHz
3. Connector
LNB IF input F type, IEC 169-24 Female
RCA AUDIO L, R
Serial Port Rs232 D-sub male type(max 57.6
Kbps)
4 Power Supply
Input Voltage 100-240V~, 50/60Hz.
Power Consumption Max.30W
Weight Appr. 1.9KG
Operating Temperature
0℃ - 40℃
Storage Temperature
-40℃- 65℃
