PART 1 • English
6
3.2 Rear Panel
Fig. 4
1. ANT IN To connect an antenna for reception of broadcasting signal.
2. TO TV To connect a TV set or to connect an extra receiver.
3. S/PDIF (Coax.) To connect your receiver to digital audio amplifier.
4. USB* Connects to USB device
* USB connector of SRT 5205 on the front
5. TV SCART To connect your receiver with your TV set using a SCART cable.
6. VCR SCART* To connect your receiver with your VCR using a SCART cable.
* Only available in SRT 5202 and SRT 5205
7. Audio L/R and Video*: Connect your receiver with your TV set using an A/V cinch cable.
* Only available in SRT 5205
8. Power Cord Your receiver requires a voltage of 220 ~ 240 V AC (Auto-selectable),
50/60 Hz +/-5 %. Make sure to check the power specification before
connecting your receiver to the wall outlet.
3.3 Remote Control
Fig. 5
1.
Turns the receiver On/Standby
2.
Mutes audio output of the receiver
3. PG+/PG- Page up/down
4. DVT/VCR To switch between TV and VCR mode
5. INFO Shows the actual channel information
6. VOL+/VOL- Volume up/down
7. MENU Opens the main menu/In menu you will get one step back
8. EXIT Exits from the menu or sub-menu
9. pq Menu Off: Change channel to previous/next.
Menu On: Moves the cursor up/down.
10. tu Menu Off: Increases/decreases the volume level.
Menu On: Change settings for specific Menus
11. OK Menu On: Activates the highlighted menu item.
Menu Off: Displays the current channel list
12. RECORD No function
13. TIMESHIFT No function
14. 0 ~ 9 Channel selection or value input
15. EPG Shows the EPG (Electronic Program Guide) in TV mode
16. RECALL Back to previous shown channel
17. AUDIO Sets the current audio channel to left, right or stereo
18. TV/RADIO Toggles between TV or RADIO mode
19. FAV Favourite group selection
20. FILE No function
21. TTX Shows Teletext on OSD (On Screen Display)
