PART 1 • English
English
2.0 CONNECTION
Connecting to TV, Terrestrial Antenna, IR Eye and Main Power Fig. 1
To receive the broadcast signal, the terrestrial antenna cable should be connected to
the ANT IN connector at the receiver. Then connect the IR connector into the receiver
and make sure it is properly connected to the IR sensor input. Afterwards you can plug
the power adapter to the main power source (100 ~ 240 V, 50/60 Hz Auto detecting).
After all connections are established carefully, the IR eye LED must light, otherwise the
Remote Control will not react.
Connection to a USB device Fig 2
Connecting to DVD Recorder Fig 3
Connecting to a Projector Fig 4
2.1 Default Pin-Code: 0000
3.0 YOUR RECEIVER
Fig. 5
1. SCART PORT To connect to your TV set.
2. Mini USB-Port To connect your included converter USB cable and then your USB
storage device
3. ANT IN To connect an antenna for reception of broadcasting signal
(support antenna power 5 V DC).
4. To TV To connect to the areal input of your TV or to a second receiver.
5. IR Sensor slot To connect IR eye plug
6. DC IN To connect the power adapter plug (5 V DC/2 A).
3.1 Remote Control
Fig. 6
1.
Turns the receiver On/Standby
2. 0~9 Channel selection or value input
3.
Mutes audio output of the receiver
4. RECALL Back to previous shown channel
5. PAGE+/PAGE- Page up/down
6. VOL+/VOL- TV mode: Volume up/down; Menu mode: navigation & change settings
7. CH+/CH- TV mode: Channel up/down; Menu mode: navigation
8. OK TV mode: Displays the current channel list;
Menu mode: Activates the highlighted menu item.
9. MENU TV mode: Opens the main menu. Menu mode: You will get one step
back. Multimedia: Go to upper folder
10. EXIT Exits from the menu or sub-menu
11. INFO Shows the actual channel information
12. SUB Shows list of subtitle languages
