5
*This user manual describes the full functionality including the recording function and may not be applicable if the software for recording via USB has
not yet been installed.
2.0 YOUR RECEIVER
2.1 PIN code default: 0000
2.2 Front and side panel
Fig. 1
1. Remote control sensor:
Receives the signal from the remote control
2. LED display: Shows channel number in operation and time in Standby
3. Standby indicator: Shows power state of the receiver: Red LED - receiver is in
standby mode
4. Power button: Switch the receiver to Standby or On.
5. CH-/CH+: To change channels without using the remote control
6. VOL-/VOL+ Decrease/Increase audio volume. VOL-/VOL+ and CH+/CH-
double as navigation buttons when
2.3 Rear panel
Fig. 2
1. SAT IN To connect to the LNB of your satellite dish for reception of
satellite broadcast signal
2. Ethernet To connect to a network switch, router or modem
3. USB For connection of USB device for Multimedia use
4. HDMI To connect to the HDMI input of your TV using a good quality
HDMI cable
5. TV SCART To connect to TV using a SCART cable
6. Audio L/R To connect to an analogue amplifier for stereo audio
7. S/PDIF coaxial To connect to a digital or home cinema audio amplifier
8. Power connector The receiver requires a wall adapter, mains voltage input
100~240V AC 50~60Hz 12V, 1.5A DC output. Please check the
local power conditions before connecting the receiver to the
mains supply.
2.4 Remote Control
Fig. 3
1. q Turns the receiver ON/Standby
2. ! To turn the sound on or off
3. 0-9 Channel number and numeric value input
4. TV/R Toggles between TV and radio mode
5. ļ No function
6. FAV To access your favourite channels. Toggles between available
favourite groups
7. 9 To switch between the last viewed channels
