8
3.3 Connecting multiple xed LNBs using a DiSEqC switch
Fig. 8
a), Connect the LNBs of your fixed antenna to the inputs of a DiSEqC switch
b), Connect the output or “to receiver” connector of the DiSEqC switch to the SAT IN connector on
your receiver.
c), Refer to section 3.1 or 3.2 for TV and mains connections.
3.4 Connecting to Ethernet
Fig.8
Connect a CAT5 cable (or higher quality) to the RJ45 connector of the unit and the other end to an
existing switch, router or modem. The default setting is Auto (DHCP) for automatically obtaining
IPs and DNS. Select DHCP Off in Menu SystemNetwork SettingIP setting to enter your own settings if
required. When setting up manually, you need to provide a unique IP address, Netmask, Gateway and
DNS for your receiver. Refer to the manual of your router or modem to setup properly. Signalling will
give momentary status of connection, like cable unplugged, local network or internet.
3.5 Connecting to digital audio amplier
Fig. 8
Connect one end of a good quality coaxial audio cable to the S/PDIF output of your receiver and the
other end to the coaxial audio input of your home theatre, amplifier or any other device supporting
digital audio.
3.6 Connecting a USB storage device
Fig. 8
NOTE It is recommended to use USB 2.0 or higher storage devices for recording
and play back of TV programmes or HD movies.*
NOTE Timeshift/recording and playback only works properly when a fast
USB storage device such as a USB2.0 HDD is connected to the receiver.
Timeshift/recording and playback of HD content requires a sufficient read/
write speed of the used USB storage device.*
*This user manual describes the full functionality including the recording function and may not be applicable if the software for recording via USB has
not yet been installed.
4.0 FIRST TIME INSTALLATION
After all connections have been made properly, switch on your TV and make sure the receiver is
connected to the main power. If you are using the receiver for the first time or restored to factory
default, the Installation guide menu will appear on your TV screen. Use tu to select the OSD
Language of your preference. Set the other options as are appropriate for your situation. HDMI output
is always available.TV format with HDMI connection is 16:9 Wide screen.
