PART 2 • English
A.2 SPECIFICATIONS
Demodulator
Demodulation: QPSK, 8PSK
Input symbol rate: DVB-S QPSK: 1 ~ 45 Ms/s
DVB-S2 8PSK/QPSK: 10~30 Ms/s
FEC decoder: Auto, 1/2, 2/3, 3/4, 5/6, 7/8 in DVB-S mode
Auto, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 in DVB-S2 mode
Auto, 3/5, 2/3, 3/4, 5/6, 8/9, 9/10 in 8PSK mode
Video Decoder
Profile level: MPEG-2 MP@ML, MP@HL, MPEG-4 H.264/AVC
Input rate: Max. 90 Mbit/s
Aspect ratio: 4:3 Pan & Scan, Letterbox, 16:9 Pillarbox, Full screen
Frame rate: 25 Hz for PAL
Video resolution: 576i, 576p, 720p, 1080i
Audio Decoder
Audio decoding: MPEG-1 Layer 1 & 2, Dolby Downmix
Audio mode: Mono L/R, Stereo, Dolby Digital
Sampling rate: 32, 44.1, 48 kHz
Tuner
Type1 F Type, IEC169-24, Female
Input frequency range: 950 – 2150 MHz
RF impedance: 75 Ohm unbalanced
Signal level: -75 to -25 dBm
LNB power: 13/18 V DC (+/- 5%), max. 0.5 A, overload protected
DiSEqC versions: 1.0, 1.2, GOTO X
Smart Card Reader
Number of slots: 1
Standard: ISO 7816
Irdeto Version: 3.6.20
System & Memory
Main processor: Broadcom 7402
Flash memory: 16 MByte
SDRAM: 128 MByte
Connectors
SAT IN
HDMI (V/A - Output) Type A - Version: 1.2 HDCP 1.1
TV SCART (RGB, CVBS, Audio L/R output with volume control)
RCA output - Audio L/R
Digital audio S/PDIF optical
Data interface – serial port: RS 232, 9-Pin D-Sub Female type
Ethernet Service Port
Multimedia:
Audio playback – MP3 format
Picture view – JPEG format
General Data
Supply voltage: 220 - 240 V AC, 50 Hz
Power consumption: typ. 17 W, max. 33 W
Power consumption in stand-by: < 15 W
Operating temperature: +0°C to +40°C
Storage temperature: -10°C to +70°C
Operating humidity range: 25~75% RH, non-condensing
Size (W x H x D) in mm: 360 x 280 x 56
Weight: 2,02 kg
