1. Note: Kick Panels Are NOT To Be On
Case During Removal From Pallet!
Kick panels can easily buckle or bend while
removing from pallet.
If kick panels are on case, remove by lifting
up and off. No screw removal is required to
remove kick panels.
After unit is in position, kick panels are to be
placed on case.
2. Remove Unit From Pallet
For your safety, the equipment is furnished
with a properly grounded cord connector. Do
not attempt to defeat the grounded connector.
Fork Lift
To lift case up for lift-truck forks to slide into
position, use J-Bar lift tab.
Make certain case is
well-supported on lift
truck. Move into
position.
KICK PANEL REMOVAL / REMOVAL OF CASE FROM PALLET / POSITIONING UNIT
6
3. J-Bar or Dolly Only (No Fork Lift)
Slide case to edge of pallet.
With several people in position, carefully slide
frame support rail to edge of pallet.
With several people in position, slide case several
more inches (off pallet) and lower rear frame
support to floor.
Once the rear frame support rail rests on the floor,
have several people supporting front of case while
pallet is slid out from under case.
After case is off pallet, several employees may be
required to slide into position.
4. Positioning Unit
Place unit into desired location before leveling.
See next page for leveling specifics.
Note! Kick Panels Are NOT To Be On
Case During Removal From Pallet!
View of Unit WITHOUT
Kick Panels Attached
To Next Page
