Struers LaboPol-35 - Circuit Diagram

W1
Power Entry Module
with main power switch
F1 + F2
POWER OUTLET TO
E.G.: THERMAL PROTECTION IN SAMPLE MOVER
2x 4,0 AT
X2
EXTERNAL EQUIPMENT
4
2
PE
X1
7 (Common)
8
9
20 (+12V dc)
K14
E1
K12 E28
S1 (on front)
START
S2 (on front)
STOP
S3 (on front)
LOW / HIGH
SPEED
E2 E3
200-240 V / 50-60 Hz
L1
N / L2
PE
MUST BE CONNECTED
TO A PROTECTIVE
EARTH CONNECTION
V
W
PE
U
V
PE
W
U
+temp.
(120C)
A1 M1
S4 (on back)
EXTERNAL EQUIPMENT
ACTIVE / NON ACTIVE
STOP SIGNAL FROM
EXTERNAL
EQUIPMENT
X3
RP1 (on front)
SET SPEED
FREQUENCY INVERTER MOTOR
L1
N / L2
PE
1K
+
-
1234
1
1A
3
2
1
Only on:
LaboPol-4
LaboPol-5
LaboPol-6
LaboPol-25
LaboPol-35
Only on:
LaboPol-2
Plug-In Module
(Machine setup)
EPM
K1
PLATE
MOUNTING
PLATE
MOUNTING
PLATE
MOUNTING
PLATE
MOUNTING
PLATE
MOUNTING
PLATE
BOTTOM
PLATE
BOTTOM
YE/GN
CHASSIS
ALU.
PLATE
BOTTOM
(MOTOR PLATE)
FRONT
PLATE
YE/GN YE/GN
PLATE
BOTTOM
YE/GN
FOUNDATION
DISK
LABOPOL-21/25 ONLY
FTH / FTH
C
3-Phase motor
240V / 60Hz
M1 motor data:
LaboPol-1: 4-poles, 250W (1/3 H.P.)
LaboPol-2: 4-poles, 250W (1/3 H.P.)
LaboPol-21: 4-poles, 250W (1/3 H.P.)
LaboPol-25: 4-poles, 250W (1/3 H.P.)
LaboPol-4: 8-poles, 80W (1/9 H.P.)
LaboPol-5: 4-poles, 250W (1/3 H.P.)
LaboPol-6: 4-poles, 250W (1/3 H.P.)
LaboPol-35: 4-poles, 370W (1/2 H.P.)
Note:
On LaboPol-21/25
U is connected to V and
V is connected to U
Note:
1
3
2
A21
22B
S4
Rev.B: FTH 31-10-2007
R1 resistor added in Power Switch X1
R1
220k, 1W
External Fuse
Max. 16 Amp.
Rev.C: FTH 28-08-2009
LaboPol-35 added
PHONE: +45 3670 3500
STRUERS A/S
15863100
Friday, August 28, 2009
11
A2
VALHOEJS ALLÈ 176
DK-2610 ROEDOVRE
DENMARK
LABOPOL-SERIES, CIRCUIT DIAGRAM
<Cage Code>
Size
Scale
CAGE Code
DWG NO
Rev
Sheet
of
XPE3
XPE9
XPE10XPE6
XPE1 XPE2
XPE4
XPE11XPE7XPE5 XPE8 XPE12
L2
L1
PE
