Struers LaboPol-35 - Connecting a 1 x 100 V; 50-60 Hz

LaboPol-35
Instruction Manual
5
The 3-pin (North American NEMA 5-15P) plug is for use on single-
phase power connections.
If the plug supplied on this cable is not approved in your country,
then the plug must be replaced with an approved plug. The leads
must be connected as follows:
Green: earth
Black: phase (live)
White: neutral
On the other end the cable is equipped with an IEC 320 cable
connector that has to be connected to the LaboPol-35.
Connecting a 1 x 100V / 50-60
Hz:
Single-phase Supply
Connection to the Machine
WARNING!
The output voltage from this cable is 200 – 240V and not 110V.
DO NOT use this cable to connect equipment that use an 110V power
supply. Failure to adhere to this may result in material damage.
IMPORTANT
If no specimen mover is connected to the LaboPol-35,
remember to set the switch “specimen mover” into the off position.
Otherwise the LaboPol-35 cannot be started.
