Base with Dual Side Hydraulics (Fifth Wheel Base)
33
See Detail A
DETAIL A
Insert item ”T” into
keyhole in item ”V”
and push down
to assemble
Insert spring hook onto hook
on release pedal. Insert other
hook onto pump connecting
rod as shown.
Insert spring hook thru
hole in pump connecting
rod. Attach other hook to
return spring as shown
