Optional 2−Stage I.V. Pole Mounting Assembly
101
Assembly part numbers
HEAD END
1510−280 (Foot End)
1510−281 (Head End)
FOOT END
Item Part No. Part Name Qty.
A(page 102) I.V. Pole Assembly 1
B 1001−259−103 I.V. Pivot 1
C 0016−11 8 −000 Nyock Nut 3
E 0004−452−000 But. Hd. Cap Screw 1
F 0003−356−000 Hex Hd. Cap Screw 2
H 0016−11 6 −000 Flexlock Nut 1
J 1509−11 0 −001 I.V. Plug 1
