Introduction
INTRODUCTION
This manual is designed to assist you with the maintenance of the 1550 Electric Stretcher. Read it thoroughly
before beginning any maintenance on the equipment.
SPECIFICATIONS
Safe Working Load 500 pounds (227 kilograms)
Overall Bed Length/Width 83.5”/34”
Minimum/Maximum Bed Height 22”/35”
Knee Gatch Angle 0 to 30
Fowler Angle 0 to 70 (Electric), 0 to 90 (Crank)
Trendelenburg/Reverse Trendelenburg +18/−18
Electrical Requirements 110 VAC, 60 Hz, 7.0 Amp
Weight of Product 340 pounds (154 kilograms) − standard configuration
400 pounds (181 kilograms) − all options/accessories
Stryker reserves the right to change specifications without notice.
SPECIFICATIONS (OPTIONAL SCALE SYSTEM)
Optional Scale System Weight Operating Range 0 lbs. to maximum capacity of the stretcher
Optional Scale System Accuracy Between 10° Trend & 10° reverse Trend*
2 lbs. of weights below 100 lbs.
2% of weights above 100 lbs.
Environmental Conditions Operation Storage and Transportation
Temperature
Relative Humidity
Atmospheric Pressure
* Scale does not meet accuracy claims at Trend angles outside the specified range.
