Service Information
31
SIDERAIL PATIENT CONTROL REPLACEMENT
Required Tools:
5/64” Allen Wrench
Procedure:
1. Unplug the power cord from the wall socket. Properly ground yourself (see page 11). Lower the siderail.
2. Peel the label off the siderail top rail.
3. Using a 5/64” Allen wrench, remove the two screws from the top rail.
4. Pull the control assembly out of the inside of the top rail and disconnect the cable from the switch board
inside the rail.
5. Reverse the above steps to install the new control assembly, being sure the cable is aligned with the
groove in the switch housing and isn’t pinched when the control assembly is installed.
6. Plug the stretcher power cord into a properly grounded wall receptacle and be sure the siderail control is
working properly before returning the stretcher to service.
Return to Table of Contents
