Stryker 1550 Service Manual

3−Sided Control Base Assembly, Non−Electric Lift
39
Item Part No. Part Name Qty. Item Part No. Part Name Qty.
A 715−1−11 Brake Cushion 4 BR 3−47 Hex Hd. Cap Screw 4
B 715−1−61 Caster Brake Weldment 2 BT 3−62 Hex Hd. Cap Screw 8
C 715−1−92 Pump Pedal Shaft 1 BU 3−85 Hex Hd. Cap Screw 8
D 715−201−94 Compression Spring 2 BX 4−146 Soc. Hd. Cap Screw 2
E 715−1− 8YB1ralloC331 −17 Shoulder Bolt 2
F 715−1−140 Vinyl Tube 2 BZ 11−3 Washer 9
G (page 69) Brake Adjuster Assembly 2 CA 11−13 Washer 1
H 3001−200−52 Ground Chain 1 CB 11−262 Washer 11
K 715−1−158 Caster Nut 4 CC 13−38 Ext. Tooth Lock Washer 4
L 715−1−165 Actuator Plate Wldmt. 2 CD 14−2 Washer 11
M 715−1−192 Jack Support 2 CE 14−3 Washer 2
N 715−1−193 Jack Support Clamp 2 CF 14−7 Washer 7
S (page 40) Caster Assembly 4 CG 14−9 Washer 2
U 1061−201−83 Pump Pedal Assembly 1 CH 14−21 Washer 3
V 715−201−126 Slip On Pump Pedal 3 CJ 15−11 Hex Nut 4
Y (page 70) Brake Cam Assembly 2 CK 16−2 Hex Nut 2
Z 715−201−230 Brake Bar 1 CL 16−14 Nylock Nut 1
AA 716−1−15 Release Pivot Bar 2 CM 16−28 Hex Nut 4
AB 716−1−52 Pivot Assembly, Foot End 1 CN 16−36 Hex Nut 16
AC 716−1−102 Pump Link Wldmt., Ft. End 1 CP 16−48 Hex Nut 1
AD 716−1−119 Pivot Assembly, Hd. End 1 CR 16−49 Hex Nut 2
AE 716−201−281 Pump Idler Link 1 CS 46−2 Sq. Hd. Set Screw 2
AF 716−1−286 Release Ball Spacer 2 CT 21−151 Set Screw 2
AG 716−201−61 Release Pedal Pivot Rod 1 CU 3−364 Hex Washer Head Screw 1
AH 716−301−70 Long Release Rod 1 CW 25− 2teviR05
AK 716−301−72 Medium Release Rod 1 CX 26−13 Spring Pin 2
AL 716−301−74 Release Rod 1 CY 26−195 Clevis Pin 2
AM (page 71) Pump Pedal Ass’y, Ft. End 1 DA 27−4 Cotter Pin 7
AN 763−1−15 Jack Spring 1 DB 27−3 Cotter Pin 7
AP 763−1−16 Spring Holder 1 DC 27−16 Cotter Pin 7
AR 946−1−116 Brake Bar Bushing 4 DD 28−97 Ext. Retaining Ring 1
AS 1210−101−112 Rel. Rod, Head End, Lt. 1 DE 29−7 Dual Lock 7
AT 1210−1−115 Pedal Pivot, Lt. 1 DF 29−9 Dual Lock 7
AU 1210−1−114 Pedal Pivot, Rt. 1 DG 38−335 Desc. Pedal Return Spring 2
AX 1210−1−123 Rel. Pedal Trans. Wldmt. 1 DH 38−451 Pump Return Spring 1
AY 1210−1−134 Rel. Pedal Linkage 1 DI 38−326 Extension Spring 2
AZ 1210−1−138 Release Rod Clamp 2 DJ 38−355 Extension Spring 2
BA 1210−201−28 Pump Rod Ass’y Angle 1 DK 42− 2ralloC02
BB 1210−201−104 Slip Link Assembly 1 DL 52−245 Nyliner 4
BC 1210−201−111 End Rel. Pedal Bracket 1 DM 52−284 Spacer 4
BD 1210−201−120 Base Frame Weldment 1 DN 52−302 Flange Bearing 2
BF 1210−201−152 Side Rel. Pedal Wldmt. 2 DP 52−747 Flange Bearing 4
BG 1210−201−153 Butterfly “V” Pedal 2 DT 11−4 Washer 1
BH 1210−201−155 Foot Rel. Pedal, Offset, Lt 2 DU 11−350 Washer 1
BJ 1210−201
−201 Pivot Pin Bracket, Foot End 1 DW 26−143 Groove Pin 5
BK 1210−201− 72XD3tresnI152 −20 Rue Cotter Pin 4
BL 1210−301− 5188YD1gnirpS252 −005−800 Ext. Tooth Lock Washer 2
BM 1210−201−550 Wear Plate 2 DZ 16−102 Fiberlock Nut 2
BN 1210−201−551 Eyebolt 1 EA 715−1−116 O2 Bottle Cushion 1
BP 3−3 Hex Hd. Cap Screw 4 EB 12−12 Lock Washer 2
EC 13-18
External Tooth Washer 1
