716−201−292 Head End Pump Pedal Assembly
72
G
D
B
C
A
F
E
Item Part No. Part Name Qty.
A26−145 Spring Pin 1
B 716−1−285 Pump Pivot Housing, Hd. End 1
C 716−201−14 Head End Pump Rod 1
D 715−201−126 Pedal 1
E 1210−201−551 Eye Bolt 1
F16−14 Nylock Nut 1
G26−261 Groove Pin 1
