Stryker 1550 Service Manual

97
Quick Drop Fowler & Gatch Assembly
Item Part No. Part Name Qty.
A 1550−33−28 Drive Bar Weldment 1
B 1550−33−14 Fowler Crkscr. Detent Ass’y 1
C 1550−33−25 Quick Drop Brkt. Ass’y, Rt. 1
D 1550−33−26 Quick Drop Brkt. Ass’y, Lt. 1
E 1550−33−19 Release Arm Weldment 1
F 1550−33−20 Handle Guard 2
G 1550−33−36 Right Release Label 1
H 1550−33−37 Left Release Label 1
J 1550−33−38 E−Drop Release Label, Left 1
K 1550−33−43 E−Drop Release Label, Right 1
L 1550−33−11 Spring/Cable Pin 2
M 1550−33−18 Cable Retainer 2
N 1550−33−16 Cable Return Arm 2
P 1550−33−29 Drive Tube Stop 3
R37−200 Vinyl Cap 2
S 1550−33−9 Fowler/Gatch Release Cable 2
T 1550−34−16 Gatch Detent Arm Ass’y 1
V 1550−34−7 Knee Gatch Ckscr. Extension 1
W 1550−31−2 Threaded End Fitting 2
X 1550−31−1 Fowler Gas Cylinder 1
Y(page 98) Fow. Ckscr. Ass’y, w/ Act. 1
Z(page 99) Gat. Ckscr. Ass’y, w/ Act. 1
AA 1550−90−23 Reset Label, Fowler 1
AB 1550−90−24 Reset Label, Gatch 1
AC 4−5 Soc. Hd. Cap Screw 2
AD 4−29 Soc. Hd. Cap Screw 3
AE 16−47 Nylock Nut 2
AF 21−8 Set Screw 4
AG 38−285 Extension Spring 2
AH 38−284 Extension Spring 2
AJ 11−77 Washer 4
AK 14−55 Washer 4
AL 28−114 Retaining Ring 4
AM 16−28 Nylock Nut 4
AN 14−21 Washer 4
AP 37−95 End Cap 2
AR 3−47 Hex Hd. Cap Screw 4
AS 25−79 Pop Rivet 10
AT 1550−34−22 Cable Guide 1
AV 59−75 Nylon Cable Tie 2
AX 16−36 Flexlock Nut 3
AY 3−68 Hex Hd. Cap Screw 1
AZ 4−108 Hex Hd. Cap Screw 1
BA 16−35 Nylock Nut 1
