EN-9
The Crossfire™ Console
e Crossre™ console is the connection hub for the components of the
Crossre™ system. It generates RF energy, powers motorized shavers, and
provides user controls and system feedback.
Front Panel
e front console panel features ports for connecting handpieces, controls for
adjusting handpiece settings, and an LCD screen to provide system feedback.
1 2
5 6 7 8 9
3 4
1. Menu Selects menu items
2. Select Selects which device displays on
the LCD screen.
3. RF connector SERFAS Energy probe
4. Handpiece connector Powered shaver handpiece
5. Power Powers the console on and o
6. Error indicator Shines red to indicate errors (error
details appear in the LCD)
7. LCD screen Provides system feedback
8. Adjust Adjusts options for connected
devices
9. Footswitch connector Crossre™ Footswitch
